Aluminum PCB

Aluminum PCBs are printed Circuit Boards that contain a thin layer of conductive dielectric material. They are also known as Aluminum Clad, Aluminum base, MCPCB, IMS, Thermally Conductive PCBs.

Aluminum PCB

Among all-metal core PCBs, also known as MCPCBs for their ability to provide effective thermal dissipation for electronic products, Aluminum PCBs is the most common type – the base material consists of aluminum core with standard FR4. It features a thermal clad layer that dissipates heat in a highly efficient manner, while cooling components and increasing the overall performance of the products. Currently, Aluminum Backed PCBs is regarded as the solution to high power and tight tolerance applications.

Outsource Aluminum PCB to Bester

  • Reduced Costs
  • Increased Productivity
  • Experienced Techinicans

Aluminum PCB Meet High-Quality Standards

Bester has been manufacturing MCPCB Boards for 10+ years. Our full feature aluminum circuit boards making capabilities and Free DFM Check allow you to get high-quality aluminum PCBs done within budget. Our printed Aluminum PCBs are widely used for LED lighting, power equipment and automotive systems.

Aluminum PCB Product Specifications

FeatureCapabilities
Quality GradeStandard IPC 2
Number of Layers4 – 24layers
Order Quantity1pc – 10000+pcs
Build Time2days – 5weeks
MaterialAluminum core (Domestic 1060), Copper core, FR4 covering
Board SizeMin 6mm x 6mm
Max 610mm x 610mm
Board Thickness0.8mm – 5.0mm
Copper Weight (Finished)0.5oz – 10.0oz
Min Tracing/Spacing4mil/4mil
Solder Mask SidesAs per the file
Solder Mask ColorGreen, White, Blue, Black, Red, Yellow
Silkscreen SidesAs per the file
Silkscreen ColorWhite, Black, Yellow
Surface FinishHASL – Hot Air Solder Leveling
Lead Free HASL – RoHS
ENIG – Electroless Nickle/Immersion Gold – RoHS
Min Annular Ring4mil
Min Drilling Hole Diameter6mil
Other TechniquesCountersink holes
Screw holes

Explore Our PCB Products

Bester Tech offers PCB fabrication & manufacturing service, providing consistently top-notch quality printed circuit boards at most reasonable prices.

Bester Tech strives to meet your PCB fabrication needs in various materials and technologies, with an unwavering commitment to global high industry standards, whether a single board for a prototype or large volume production runs. We now focus and support projects including standard, advanced, HDI, multilayer PCBs, flexible, rigid-flex boards, aluminum PCBs, prototypes to small batches.

We have the PCB manufacturing capabilities to build simple to complex bare boards. Please review the example printed circuits below and let us know if you have any questions or would like a formal quote

RIGID PCB

Rigid PCB is a type of regular PCB which can not be twisted or folded into any shape because it comes with FR4 stiffener which is very useful for added amount of stiffness and rigidity.

FLEX PCB

Flexible circuits (also variously referred to around the globe as flex circuits, flexible printed circuit boards, flex print, Flexi-circuits) are members of electronic and interconnection family.

RIGID-FLEX PCB

Rigid-Flex printed circuit boards are boards using a combination of flexible and rigid board technologies in an application. Most rigid flex boards consist of multiple layers of flexible circuit substrates attached to one or more rigid boards externally and/or internally, depending upon the design of the application.

ALUMINUM PCB

Among all metal core PCBs (aka MCPCBs, known for their ability to provide effective thermal dissipation for electronic products), Aluminum PCBs is the most common type – the base material consists of aluminum core with standard FR4.

HDI PCB

HDI PCB is widely used to reduce the weight and overall dimensions of products, as well as to enhance the electrical performance of the device.

HIGH FREQUENCY PCB

A high-frequency PCB can meet your needs when incorporating a special signal requirement into your electronic components and products.
