Flexible PCB
Flex PCB consist of a thin insulating polymer film having conductive circuit patterns affixed thereto and typically supplied with a thin polymer coating to protect the conductor circuits
Flexible PCB
Flexible printed circuit boards, also called Flexible PCB or Flex PCB, derive their name for their ability to enable the circuitry to be designed to fit the electronic device or product, as opposed to building the device to conform to the circuit board. Flex boards are characterized by a distinctly patterned printed circuitry and component arrangement highlighted by a malleable base material.
Outsource Flexible PCB to Bester
- Reduced Costs
- Increased Productivity
- Experienced Techinicans
A Leading Flex Circuit Manufacturer
At Bester, we specialize in the fabrication and assembly of flexible PCB products for use in the manufacturing of medical devices and various types of telecommunication and industrial equipment. Our custom PCB manufacturing capabilities allow us to develop and produce a top-performing flex PCB that meets your unique requirements. We can also work with you to produce a custom flex PCB prototype that will significantly improve your prospects of a successful project outcome. For detailed capabilities, please refer to the following form.
Flexible PCB Product Specifications
| Feature | Capabilities |
|---|---|
| Quality Grade | Standard IPC 2 |
| Number of Layers | 1 – 8layers |
| Order Quantity | 1pc – 10000+pcs |
| Build Time | 2days – 5weeks |
| Material | DuPont PI, Domestic Shengyi PI |
| Board Size | Min 6mm x 6mm Max 406mm x 610mm |
| Board Thickness | 0.1mm – 0.8mm |
| Copper Weight (Finished) | 0.5oz – 2.0oz |
| Min Tracing/Spacing | 3mil/3mil |
| Solder Mask Sides | As per the file |
| Solder Mask Color | Green, White, Blue, Black, Red, Yellow |
| Solder-stop coating—Soldermask oil | Green, White, Blue, Black, Red, Yellow |
| Solder-stop coating—Coverlay | PI and PET film |
| Silkscreen Sides | As per the file |
| Silkscreen Color | White, Black, Yellow |
| Surface Finish | HASL – Hot air solder leveling Lead – free HASL – RoHS ENIG – RoHS Immersion Tin – RoHS OSP – RoHS |
| Min Annular Ring | 4mil |
| Min Drilling Hole Diameter | 8mil |
| Min. hole size—Drilling (PTH) | 0.2mil |
| Min. hole size—Punching (NPTH) | 0.5mil |
| Tolerance of dimension | ±0.05mm |
| Other Techniques | Peelable solder mask Gold fingers Stiffener (only for PI/FR4 substrate) |
