PCB Prototype

For PCB prototyping, we are able to manufacture low volume single and double-sided PCBs to complex multilayer PCBs with blind and buried vias at affordable prices.

PCB Prototype

A prototype printed circuit board is an essential step in the design process of an electrical item. Printed circuit boards use conductive tracks to connect components.

If you need prototype printed circuit boards, it’s important to work with an assembler who can turn your designs around fast. These boards help verify you have the right design before you start a full production run so you can avoid costly errors. The sooner you get your prototype circuit board back, the sooner you can test it and get started on your standard production run. Bester is the PCB manufacturer with fast reaction. We offer quick-turn PCB prototypes to turn your prototype boards around fast while still maintaining complete adherence to your design specifications.

Order PCB Prototype with Bester

  • Quick-turn
  • High Quality
  • Low Cost
  • Fast Delivery

Prototype Printed Circuit Boards Meet High-Quality Standards

Bester offers rapid PCB prototyping services for quick-turn PCB at high quality and low cost. We’re fully compliant with ISO9001:2015 quality management systems, and we have an in-house quality control department to verify that all work meets each regulation depicted by the high standards.

Depending on your custom requirements, we can prototype your PCB within 3-7 days, compared to 6-18 days of Standard PCB service. Check out our circuit board prototype capabilities in the following table

PCB Prototype Product Specifications

FeatureCapabilities
Quality GradeStandard IPC 1
Number of Layers1 – 8 layers
Order Quantity5 – 100pcs
Build Time2 – 7 days
MaterialFR-4 Standard Tg 140°C
Board SizeMin 6mm x 6mm
Max 500mm x 500mm
Board Thickness0.4mm – 2.0mm
Copper Weight1.0oz – 2.0oz
Min Tracing/Spacing5mil/6mil (copper weight: 1oz)
8mil/8mil (copper weight: 2oz)
Solder Mask SidesAs per the file
Solder Mask ColorGreen, White, Blue, Black, Red, Yellow
Silkscreen SidesAs per the file
Silkscreen ColorWhite, Black
Surface FinishLead Free HASL – RoHS
HASL – Hot Air Solder Leveling
ENIG – Electroless Nickle/Immersion Gold – RoHS
Min Annular Ring5mil
Min Drilling Hole Diameter8mil
Min Width of Cutout (NPTH)0.8mm
Min Width of Slot Hole (PTH)0.6mm
Surface/Hole Plating Thickness20μm – 30μm
Aspect Ratio10:1 (board thickness: hole size)
Test10V – 250V, flying probe or testing fixture

Explore Our PCB Products

Bester Tech offers PCB fabrication & manufacturing service, providing consistently top-notch quality printed circuit boards at most reasonable prices.

Bester Tech strives to meet your PCB fabrication needs in various materials and technologies, with an unwavering commitment to global high industry standards, whether a single board for a prototype or large volume production runs. We now focus and support projects including standard, advanced, HDI, multilayer PCBs, flexible, rigid-flex boards, aluminum PCBs, prototypes to small batches.

We have the PCB manufacturing capabilities to build simple to complex bare boards. Please review the example printed circuits below and let us know if you have any questions or would like a formal quote

RIGID PCB

Rigid PCB is a type of regular PCB which can not be twisted or folded into any shape because it comes with FR4 stiffener which is very useful for added amount of stiffness and rigidity.

FLEX PCB

Flexible circuits (also variously referred to around the globe as flex circuits, flexible printed circuit boards, flex print, Flexi-circuits) are members of electronic and interconnection family.

RIGID-FLEX PCB

Rigid-Flex printed circuit boards are boards using a combination of flexible and rigid board technologies in an application. Most rigid flex boards consist of multiple layers of flexible circuit substrates attached to one or more rigid boards externally and/or internally, depending upon the design of the application.

ALUMINUM PCB

Among all metal core PCBs (aka MCPCBs, known for their ability to provide effective thermal dissipation for electronic products), Aluminum PCBs is the most common type – the base material consists of aluminum core with standard FR4.

HDI PCB

HDI PCB is widely used to reduce the weight and overall dimensions of products, as well as to enhance the electrical performance of the device.

HIGH FREQUENCY PCB

A high-frequency PCB can meet your needs when incorporating a special signal requirement into your electronic components and products.

READY FOR THE NEXT STEP?

Need custom specifications, pricing, delivery information or samples?
