What is Files Ivex

By Bester PCBA

Last Updated: 2023-12-12

Table of Contents

What is Files Ivex

Files Ivex refers to a file format or type associated with the Ivex WinBoard program, which is used for designing printed circuit boards. In Ivex WinBoard, the default orientation of the files is mirrored, meaning that instead of viewing the board from the top, it is viewed from the bottom. To ensure proper orientation during CAD conversion or file submission, it is recommended to include “right reading” text on the top layer and name the file extensions as *.L1, *.L2, and so on.
